Upright TL38 - Ground Controls Assembly

Page 6-16
Illustrated Parts Breakdown - Ground Controls Assembly
TL38 Service & Parts
Ground Controls Assembly
502546-000
Item Part Description QTY.
1 057309-000 EMERGENCY STOP BUTTON 1
* 508033-000 CONTACT BLOCK (EM STOP) 1
2 502560-000 SOCKET 1
3 503288-000 DECAL 1
4 501866-000
KEY SWITCH (501866-001 FOR THE KEY
ALONE)
1
5 502539-000 ANALOG ROCKER 1
6 502451-000 ECU 1
7 502561-000 ALARM 1
8 502492-000 MOTOR CONTROLLER 1
9 502489-000 LINE CONTACTOR 1
10 501878-000 FUSE 1
11 501877-000 FUSE BLOCK 1
12 502562-000 SOCKET 1
13 502457-000 CIRCUIT BOARD 1
