Page 6-15
Illustrated Parts Breakdown - Platform Controls Assembly
TL38 Service & Parts
Platform Controls Assembly
Item Part Description QTY.
1 502453-000 CIRCUIT BOARD 1
2 501866-000 KEY SWITCH 1
3 501867-000 EMERGENCY STOP BUTTON 1
4-000DECAL 1
5 501881-000 ENCLOSURE 1
6 501882-000 JOYSTICK 1
7 501882-002 JOYSTICK BOOT 1
8 501882-001 JOYSTICK STEERING BOOT 1
9 501866-001 KEY 1
