Upright TL38 - Tow Hitch Assembly

Page 6-14
Illustrated Parts Breakdown - Tow Hitch Assembly
TL38 Service & Parts
Tow Hitch Assembly
058241-000
Item Part Description QTY.
1 058348-000 COUPLING HEAD, EUROPE 1
* 058349-000 COUPLING HEAD, USA 1
2 058790-000 GAITER 1
3 058242-000
JOCKEY WHEEL
(NOT PART OF TOW HITCH ASSEMBLY)
1
4 058787-000 HANDBRAKE ASSEMBLY 1
5 058794-000 SPRING PACK ASSEMBLY 1
6 058746-000 BREAKAWAY SAFETY CABLE 1
1
1
2
1
2
3
4
5
6
