Upright TL38 - Hydraulic Assembly

Page 6-24
Illustrated Parts Breakdown - Hydraulic Assembly
TL38 Service & Parts
Hydraulic Assembly
500113-000
Item Part Description QTY.
1
500104-000
HOSE ASSY, 3/8” M1T 400mm B90-B90 @
90º
PUMP TO T JUNCTION
1
2
500105-000
HOSE ASSY, 1/2” M1T 85mm B90-B90 @
180º
T JUNCTION TO FILTER
1
3
500106-000
HOSE ASSY, 3/4” M1T 210mm BF-B90
HYDRAULIC TANK TO PUMP
1
4
500107-000
HOSE ASSY, 1/2” M1T 580mm B90-B90 @
270º
RETURN LINE FROM PUMP TO TANK
1
5
500108-000
HOSE ASSY, 1/2”M1T 520mm B90-B90 @
90º
RETURN LINE FROM FILTER TO TANK
1
6
500109-000
HOSE ASSY, 1/4” M1T 750mm B90-BF
MAIN MANIFOLD TO SLEW MOTOR
2
7
500110-000
HOSE ASSY, 1/4” M1T 11350mm B90-
BANJO
MAIN MANIFOLD TO JIB CYLINDER
2
8
500111-000
HOSE ASSY, 1/4” M1T 5350mm B90-B90
MAIN MANIFOLD TO BOOM 2
2
9
500112-000
HOSE ASSY, 1/4” M1T 900mm B90-B90
MAIN MANIFOLD TO BOOM 1
2
10
500121-000
HOSE ASSY, 1/4” M1T 1040mm
B90-1/8”BF
SLEW MOTOR DRAIN TO TANK
1
11
500114-000
HOSE ASSY, 1/2” M1T 1200mm BF-BF
RETURN LINE FROM MAIN MANIFOLD
TO T JUNCTION
1
12
500115-000
HOSE ASSY, 3/8” M1T 1100mm BF-BF
PUMP-T JUNCTION-MAIN MANIFOLD
1
13
500116-000
HOSE ASSY, 1/4” M1T 2080mm
BF- BANJO
OUTRIGGER MANIFOLD TO O.R. F.R.
2
14
500117-000
HOSE ASSY, 1/4” M1T 1530mm
BF-BANJO
OUTRIGGER MANIFOLD TO O.R. F.L.
2
15
500118-000
HOSE ASSY, 1/4” M1T 2080mm
BF-BANJO
OUTRIGGER MANIFOLD TO O.R. R.R.
2
16
500119-000
HOSE ASSY, 1/4” M1T 1480mm
BF-BANJO
OUTRIGGER MANIFOLD TO O.R. R.L.
2
Item Part Description QTY.
