Illustrated Parts Breakdown - Decal Assembly
TL38 Service & Parts
Decal Assembly
German CE - 500391-0032
Item Part Description QTY.
1-- -
2-- -
3
058608-000 DECAL - LOWER CONTROL BOX
1
4-- -
5
058860-000 DECAL - HAND HAZARD
3
6
057385-000 HAZARD TAPE (900mm LONG)
8
7
058609-000 DECAL - ‘UPRIGHT LOGO’
2
8
057339-001 DECAL - PLASTIC PUSH RIVET
2
9
058838-000 E.U. NAMEPLATE
1
10
058836-000 V.I.N. PLATE
1
11 - - -
12 - - -
13
058607-000 DECAL - UPPER CONTROL BOX
1
14 - - -
15 - - -
16 - - -
17
057387-000 DECAL - UPPER QUADRAPOWER
1
18 057507-005 DECAL - UNIT WEIGHT 1500KG 1
19 - - -
20 - - -
21 - - -
22
057507-010 DECAL - ARROW
2
23 - - -
24
057507-027 DECAL - MACHINE NOT INSULATED 2
25
057420-002 DECAL - ACTION ON ALARM
2
26
057507-002 DECAL - EMERGENCY LOWERING
2
27
057416-002 DECAL - BEFORE TOWING
1
28
057418-002 DECAL - STOW OUTRIGGERS
2
29
058186-002 DECAL - ON/OFF UPPER CONTROLS
1
30
057507-025 DECAL - MACHINE GENERAL INSTR
2
31
057507-031 DECAL - S.W.L. LARGE
1
32
057507-026 DECAL - EXPLOSION HAZARD
2
33
057507-024 DECAL - BATTERY FLUID LEVEL
2
34
057417-012 DECAL - OUTRIGGER LOWERED
4
35
058992-002 DECAL - BOOM LOCK PIN
1
36
057507-001 DECAL - EMERGENCY STOP
2
37
057507-007 DECAL - MAX SIDE LOAD
1
38
057507-021 DECAL - BUBBLE LEVEL
1
39
057507-022 DECAL - BEFORE MAINTENANCE
1
40
057507-023 DECAL - HYDRAULIC OIL
1
Decal Assembly
French CE - 500391-001
Item Part Description QTY.
1
057507-016 DECAL - MACHINE NOT INSULATED 2
2
057507-018 DECAL - ACTION ON ALARM
2
3
058608-000 DECAL - LOWER CONTROL BOX
1
4
057382-001 DECAL - EMERGENCY LOWERING
2
5
058860-000 DECAL - HAND HAZARD
3
6
057385-000 HAZARD TAPE (900mm LONG)
8
7
058609-000 DECAL - ‘UPRIGHT LOGO’
2
8
057339-001 DECAL - PLASTIC PUSH RIVET
2
9
058838-000 E.U. NAMEPLATE
1
10
058836-000 V.I.N. PLATE
1
11
057507-017 DECAL - BEFORE TOWING
1
12
057507-020 DECAL - LOCK OUTRIGGER
2
13
058607-000 DECAL - UPPER CONTROL BOX
1
14
058186-001 DECAL - ON/OFF UPPER CONTROLS
1
15
058016-001 DECAL - MACHINE GENERAL INSTR.
1
16
057392-001 DECAL - S.W.L. LARGE
1
17
057387-000 DECAL - UPPER QUADRAPOWER
1
18 - - -
19
057430-001 DECAL - EXPLOSION HAZARD
2
20
057429-001 DECAL - BATTERY FLUID LEVEL
2
21
058017-001 DECAL - LOWERING OUTRIGGER
4
22
057507-010 DECAL - ARROW
2
23
058992-001 DECAL - BOOM LOCK PIN
1
