REVENTATIVE
M
AINTENANCE
C
HECKLIST
P
REVENTATIVE
M
AINTENANCE
K
EY
Interval
Daily=each shift or every day
50h/30d=every 50 hours or 30 days
250h/6m=every 250 hours or 6 months
1000h/2y=every 1000 hours or 2 years
Y=Yes/Acceptable
N=No/Not Acceptable
R=Repaired/Acceptable
P
REVENTATIVE
M
AINTENANCE
R
EPORT
Date: _______________________________________
Owner: _____________________________________
Model No: ___________________________________
Serial No: ___________________________________
Serviced By: _________________________________
Service Interval: ______________________________
COMPONENT INSPECTION OR SERVICES INTERVAL Y N R
Batteries
Check electrolyte level Daily
Check specific gravity 6m
Clean exterior 6m
Check battery cable condition Daily
Clean terminals 6m
Hydraulic Oil
Check oil level Daily
Change filter 6m
Drain and replace oil 2y
Hydraulic
System
Check for leaks Daily
Check hose connections 30d
Check hoses for exterior wear 30d
Emergency
Hydraulic
System
Operate the emergency lowering valve and
check for serviceability
Daily
Chassis
Controls
Check switch operation Daily
Platform
Controls
Check switch operation Daily
Control Cable
Check the exterior of the cable for
pinching, binding or wear
6m
Platform
Deck and
Rails
Check fasteners for proper torque Daily
Check welds for cracks Daily
Check condition of deck Daily
Tires
Check for damage Daily
Check lug nuts (torque to 90 ft. lbs.) 6m
Hydraulic
Pump
Wipe clean 30d
Check for leaks at mating surfaces 30d
Check for hose fitting leaks Daily
Check mounting bolts for proper torque 6m
Drive Motors Check for operation Daily
Steering
System
Check hardware & fittings for proper
torque
6m
Grease pivot pins 30d
Check steering cylinder for leaks 30d
Elevating
Assembly
Inspect for structural cracks Daily
Check pivot points for wear 6m
Check mounting pin pivot bolts for proper
torque
6m
Check elevating arms for bending 6m
Chassis
Check hoses for pinch or rubbing points Daily
Check component mounting for proper
torque
6m
Check welds for cracks Daily
Tilt Sensor Check for operation 6m
Lift Cylinder
Check the cylinder rod for wear 30d
Check mounting pin pivot bolts for proper
torque
6m
Check seals for leaks 30d
Inspect pivot points for wear 6m
Check fittings for proper torque 6m
Entire Unit
Check for and repair collision damage Daily
Check fasteners for proper torque 6m
Check for corrosion-remove and repaint 6m
Lubricate 30d
Labels
Check for peeling, missing, or unreadable
labels & replace
Daily
COMPONENT INSPECTION OR SERVICES INTERVAL Y N R
