Upright X33RT - Drop Axle Assembly

Drop axle assembly
Item Part No. Qty Description
1. 11642A 2 Axle cylinder assembly
2. 12865 2 Mounting bracket, magnetic switch
3. 12557 2 Swing arm
4. 12557-10 2 Motor cover
5. 12561 2 Wheel hub, rear
6. 12563 1 Wheel tyre assembly, right hand, foam filled
7. 12564 1 Wheel tyre assembly, left hand, foam filled
8. 12571 2 Motor, hydraulic braked
9. 12769-1 4 Adaptor, male UNO to female UNO
10. 12770-330606 4 Adaptor, male UNO to female STC straight
11. 3603-06 24 Flat washer
12. 3603-12 8 Flat washer
13. 3603-12HD 8 Flat washer
14. 3603-16HD 8 Flat washer
15. 3605-06 8 Spring washer
16. 3608-12C 4 Cone-lock nut
17. 3608-16C 4 Cone-lock nut
18. 3610-06012 8 Bolt
19. 3610-06020 8 Bolt
20. 3611-06 8 Nyloc nut
21. 3616-12040 8 Bolt
22. 3616-12100 4 Bolt
23. 3616-16140 4 Bolt, modified
24. 3626-2 8 Flanged bush
25. 3636-1 2 Split pin
26. 560278 2 Switch, proximity
27. 98300-9 12 Wheel stud
28. 12770-340406 2 Male to female STC adapter, 90
O
29. 12770-35046 2 Male to female STC adapter, 90
O
30. 3603-12H 8 Washer, flat M12, hardened
SR3370 & SR2770 (CE) – 12864B page 1 - 9
Drop axle assembly
