Platform control box assembly
Item Part No Qty Description
0. 560221 1 Platform control box assembly
1. 560228 1 Platform control box
2. 560332 1 Switch, push button
3. 560225 1 Joystick controller
4. 560376 1 Internal wire harness
5. 446836 1 Switch, push/pull emergency stop
6. 0070967 1 Corrosion inhibitor
7. 3020097 1 Switch, toggle
8. 560377 4 Led lamp, green 12 volt
9. 560375 1 Gasket
10. 3049847 1 Electrical connector
11. 3020016 1 Switch, auto level
12. 560332 1 Switch, operator horn
13. 560379 1 Switch, start/kill
14. 560241 1 Placard, platform control box
15. 3040099 1 Electrical connector lock washer
16. 3040098 1 Electrical connector lock nut
17. 560272 1 Placard, emergency stop
18. 3020016 4 Switch, outriggers (if installed)
19. 446826 1 Contact block, emergency stop
20. 560378 1 Diode wire assembly
21. 563736 1 Switch, toggle
page 3 - 12 SR3370 & SR2770 (CE) – 12864B
Platform control box assembly
