Engine side tray assembly
Item Part No Qty Description
1. 2022-003 1 Clamp
2. 3603-06 20 Plain washer
3. 3603-08 20 Plain washer
4. 3603-10 7 Plain washer
5. 3605-08 4 Spring washer
6. 3610-06016 1 Metric bolt
7. 3610-06020 7 Metric bolt
8. 3610-08030 12 Metric bolt
9. 3610-10050 3 Metric bolt
10. 3610-10055 2 Metric bolt
11. 3611-06 9 Nyloc nut
12. 3611-08 8 Nyloc nut
13. 3611-10 7 Nyloc nut
14. 3618-32 1 Hose clamp
15. 11362 1 Engine assembly, SR D905 diesel
16. 11470 2 Left hand hinge
17. 11470-1 2 Right hand hinge
18. 11471-1 2 Kubota radiator mount
19. 11480 1 SR Fuel tank assembly
20. 11679 1 Left hand door weld, small
21. 11680 1 Right hand door weld, large
22. 12716-13 1 Top plate, engine and control cabinet
23. 12717 1 Engine tray
24. 65004-008 1 Rubber grommet
25. 5560179 7 Flat washer, special
26. 7630227 1 Overflow bottle
27. 8342416 1 Latch, adjustable trigger
28. PCA015 1 Rubber channel section
29. 3610-10075 2 Metric bolt
30. 2022-005 1 Clamp
SR3370 & SR2770 (CE) – 12864B page 1 - 13
Engine side tray assembly
