Upright X33RT - Scissor Arm Assembly SR2770

Scissor arm assembly SR2770
Item Part No Qty Description
1. 3603-06 6 Plain washer
2. 3603-10 2 Plain washer
3. 3605-06 4 Spring washer
4. 3606-06016 8 Countersunk socket head screw
5. 3606-06025 2 Countersunk socket head screw
6. 3610-06020 4 Bolt
7. 3610-10020 2 Bolt
8. 3610-10025 18 Bolt
9. 3610-10040 2 Bolt
10. 3611-06 2 Nyloc nut
11. 3611-10 2 Nyloc nut
12. 3619-5 16 Circlip, external
13. 3624-2 32 PermaglideBush
14. 3624-3 36 Permaglide bush
15. 3629-5062L 16 Washer, scissor pivot
16. 8626 20 Pin keeper
17. 8699 16 Pin
18. 9016 2 Pin
19. 9292 2 Pin
20. 9330 1 Arm, lower inner
21. 9331 1 Arm, Inner upper, 4th stage
22. 9332 1 Arm, inner upper
23. 9333 2 Arm, outer
24. 9465 1 Arm, inner mid
25. 9484 1 Arm, outer lower right
26. 9502 1 Arm, outer upper
27. 11143-2 1 Wear pad
28. 11380 1 Safety prop weld
29. 11381 1 Mount bracket weld
30. 11492-3 20 Tab washer
31. 11658-20 8 Wear plug
32. 11804 8 Scissor pivot pin
33. 12529 2 Arm, outer mid
34. 12530 2 Arm, outer mid
35. 12566 2 Sliding block weld
36. 12566-2 2 Wear pad slider block, bottom
37. 12566-36 12 Slider block, top
38. 12589 1 Slider bar weld
39. 45248-6 15 Clamp crush
40. 45248-7 3 Clamp crush (not shown)
41. 97563 18 Tek screw
42. 12746A 1 SR lift cylinder
SR3370 & SR2770 (CE) – 12864B page 1 - 21
Scissor arm assembly SR2770
