Manifold assembly, main
Item Part No Qty Description
0. 12567A 1 Main manifold valve block assembly
1. 12567-1 1 Stabiliser divert valve
2. 12567-2 1 Compensator check
3. 12567-3 1 Steering flow control
4. 12567-4 1 Steering directional valve
5. 12567-5 1 Steering relief shuttle
6. 12567-6 1 Steering pilot check
7. 12567-2 1 Steering relief check
8. 12567-8 1 Steering relief valve
9. 12567-9 1 Proportional valve
10. 12567-8 1 Lift relief
11. 12567-11 1 Lift valve
12. 12567-12 1 Drive valve, forward
13. 12567-13 1 Drive counterbalance valve
14. 12567-14 1 Drive check valve
15. 12567-15 1 Free wheel valve
16. 12567-14 1 Drive check valve
17. 12567-13 1 Drive counterbalance valve
18. 12567-18 1 Drive valve, reverse
19. 12567-19 1 Hand pump
20. 12567-20 1 Brake reset valve
21. 12567-21 1 Brake pilot check
22. 12567-22 1 Brake shuttle
23. 12567-23 1 Axle pressure reducing valve
24. 12567-24 1 Brake flow control valve
25. 12567-11 1 Brake selector valve
26. 12567-2 1 Compensator check
27. 12567-27 1 Compensator bleed
28. 12567-8 1 Main relief
29. 12567-29 1 Compensator
30. 10992-2 2 Test point, 9/16" UNO
31. 12770-330606 5 Adapter, straight, 9/16" UNO -> 3/8" STCF
32. 12770-330806 3 Adapter, straight, 3/4" UNO -> 3/8" STCF
33. 12770-330808 4 Adapter, straight, 3/4" UNO -> 1/2" STCF
34. 12770-331212 1 Adapter, straight, 1 and 1/16" UNO -> 3/4" STCF
35. 12770-340808 1 Adapter, 45
O
elbow, 3/4" UNO -> 1/2" STCF
36. 12770-350606 1 Adapter, straight, 9/16" UNO -> 3/8" STCF
37. 7025-001 1 Adapter, straight, 9/16" UNO -> 9/16" JICM
38. 7035-001 1 Plug, 9/16" UNO
page 2 - 6 SR3370 & SR2770 (CE) – 12864B
Manifold assembly, main
