ACTIVATING THE SYSTEM
http://www.miwiurmet.com.pl e-mail:miwi@miwiurmet.com.pl
25
ACTIVATING THE SYSTEM
MASTER
1. Make all connection.
2. Turn on the power supply.
3. Check diagnostic LED in the supplier. Blinking red LED means
short circuit in the phone line.
4. Check entrance panel:
• Power supply checking. Keyboard should be with backlight, on
the LED display should appear blinking dot.. In case of lack of
backlight:
- check connection and installation,
- check terminal voltage AC1 and AC2.
• Communication checking. The best way to check
communication is press any number, on the display should
appear the same number. If not:
- check connection and installation,
- check terminal voltage D (15 V DC).
• Audio checking. Call one of the door phone. In case of
problem with audio:
- check connection and installation,
- check terminal voltage LG in the keyboard
(7,5 .. 12,5 V DC).
5. If necessary change logical user code.
6. Call one of the door phone, check all functions (door release,
etc).
7. Change the installer’s code.
MASTER/SLAVE
1. Consider logical user code in the main channel.
2. Make all connection.
3. Turn on the power supply.
4. Check diagnostic LED in suppliers. Blinking red LED means
short circuit in the phone line.
5. System automatically set one of the power suppliers as
MASTER (programming step 9.7).
6. Check entrance panels:
• Power supply checking. Keyboard should be with backlight, on
the LED display should appear blinking dot.. In case of lack of
backlight:
- check connection and installation,
- check terminal voltage AC1 and AC2.
• Communication checking. The best way to check
communication is press any number, on the display should
appear the same number. If not:
- check connection and installation,
- check terminal voltage D (15 V DC).
• Audio checking. Call one of the door phone. In case of
problem with audio:
- check connection and installation,
- check terminal voltage LG in the keyboard
(7,5 ... 12,5 V DC).
7. For all power suppliers enter to the programming menu
(additional keyboards). If necessary change logical user code
in the additional panels.
8. Check main entrance panels:
• Power supply checking. Keyboard should be with backlight, on
the LED display should appear blinking dot. In case of lack of
backlight:
- check connection and installation,
- check terminal voltage AC1 and AC2.
• Communication checking. The best way to check
communication is press any number, on the display should
appear the same number. If not:
- check connection and installation,
- check terminal voltage D (15 V DC).
9. For all power suppliers enter to the programming menu
(additional keyboards).
10. In steps 8.2 or 8.3 assigned logical user code in the main
channel.
11. Check audio in main entrance panels:
Call one of the door phone. In case of problem with audio:
- check connection and installation,
- check terminal voltage LG in the keyboard
(7,5 .. 12,5 V DC).
12. Call one of the door phone from all entrance panels, check all
functions (door release, etc).
13. Change the installer’s code.
