ITEM NO. PART NO. DESCRIPTION QTY.
— 13247 Chip Guard & Slice Adjustment Assembly, (includes items 1–16) ...... 1
1 13218 Adjustment Knob, for slice gate ........................... 1
2 13237 Retaining Ring ...................................... 1
3 17021 Spherical Bearing .................................... 1
4 13226 Indicating Arm ...................................... 1
5 10224 Hex Head Cap Screw, 10-24 x 1/4" ......................... 2
6 10022 Hex Nut, 3/8-16 ...................................... 1
7 13221 Stud, 3/8-16 x 2-3/8" ................................... 1
8 13216 Chip Guard ........................................ 2
9 10308 Hex Head Cap Screw, locking, 1/4-20 x 5/8" ................... 4
10 10059 Hex Head Cap Screw, 3/8-16 x 1-1/4" ....................... 1
11 10009 Flat Washer, 3/8" ..................................... 1
12 13238 Hinge Bushing, slice adjustment ........................... 1
13 13220 Adjustment Nut, slice gate............................... 1
14 13215 Clamp, slice gate, (includes item 15)......................... 1
15 10060 Hex Head Cap Screw, 3/8-16 x 1-1/2" ...................... 1
16 13217 Support, chip guard ................................... 1
17 13545 Slice Guide, rear ...................................... 1
18 13544 Slice Guide, front ...................................... 1
19 13104 † Slicing Knife ......................................... 1
20 § Slicing Knife Holder .................................... 1
21 (see chart) Gate Extension Strip ................................... 1
22 (see chart) Hex Head Cap Screw, locking .............................. 2
23 12440 ‡ Impeller, stainless steel .................................. 1
24 10249 Hex Nut, locking, 3/8-16 .................................. 3
— 13249 Case Assembly, stainless steel, (includes items 25–33) ............. 1
25 12018 Case, stainless steel, (includes item 26) ...................... 1
26 37040 Dowel Pin, 1/4" dia. x 5/8" .............................. 2
27 12012 Case Gate, stainless steel ............................... 1
28 48125 Stud, 1/2-13 x 1-3/4" ................................... 2
29 10026 Hex Nut, 1/2-13 ...................................... 2
30 12174 Hinge Plate ........................................ 1
31 10307 Hex Head Cap Screw, locking, 5/16-18 x 1/2" .................. 6
32 12074 Clamp Block........................................ 1
33 12175 Shoulder Bolt ....................................... 2
†
For optional slicing knives, see page 100.
§
See charts, page 85.
‡
For optional impellers, see page 100.
PARTS
Slicing Unit (G-A)
Slice Item 21 Item 22
Thickness Gate Ext. Strip Screw
1/16-5/32" (1.6-4.0 mm) 12186 10250
3/16-11/32" (4.8-8.7 mm) 12188 10250
3/8-15/32" (9.5-11.9 mm) 12189 10250
1/2-23/32" (12.7-18.3 mm) 12191 10250
3/4" (19.1 mm) 12193 10298
