21
OPERATION
Installation
2
3
1
2
3
1
4
Figure 17 — Interior of starter enclosure (NEMA* configuration, top, and IEC** configuration, bottom). (1) Discon-
nect, (2) Power Source Entry Point, (3) Earth Termination Point, (4) Amplifier.
* National Electrical Manufacturers Association
** International Electrical Commission
