USSC 5660 - Heat Exchanger and Fan Cleaning

32
MAINTENANCE‐continued

Cleaning

Heat Exchanger Tubes– YourPellet StoveRoomHeateris designedwith abuiltinheatexchangertubecleaner.
Thisshouldbeusedevery2or3daystoremoveashbuildupontheheatexchangertubes,whichcanreduceheat
transfer. The handle, for the heat exchanger tube cleaner,
 is located in front of the vent tubes on front side of
heater.Slidetherodfronttobackseveraltimestocleanthetubesthenfollowtheinstructionsforashremoval.










Fans–DANGER:RISKOFELECTRICSHOCK.DISCONNECTPOWERBEFORESERVICINGUNIT

Over time ash or dust may accumulate on the blades of the circulation & exhaust fans. The fans should be
inspected,periodically,andifanyaccumulationispresentvacuumedcleanastheashordustcanimpedethefans
performance.Itis alsopossiblethatcreosotemayaccumulateintheexhaust
fantherefore,thismustbebrushed
clean.

Theexhaustfancanbefoundbehindtheleftsidepanel(facingthefrontoftheheater),thecirculationfancanbe
foundbehindtherightsidepanel.Toaccesstheigniter,removetheairinlettubeandcover(2screws)(Figure27). 

Note:Whencleaning,takecarenottodamagethefanblades.

















Figure26

Figure27
WARNING:DONOTATTEMPTTOOPERATETHEHEATEXCHANGETUBE
CLEANERWHILETHEPELLETSTOVEISINOPERATIONORCOOLING
DOWN;WAITUNTILPELLETSTOVEHASCOOLEDCOMPLETELYBEFORE
PERFORMINGTHISPROCEDURE.
