1-2 Machine Parts
Components at the Front of the Printer
1 Operation Panel
2 Front Cover
3 Paper Stopper
4 Top Cover (Top Tray)
5 MP (Multi-Purpose) Tray
6 Paper Cassette
7 Power Switch
Components at the Left of the Printer
8 Left Cover
9 Waste Toner Box
10 Main Charger Units on the Drum Units
11 Magenta Toner Container (M)
12 Cyan Toner Container (C)
13 Yellow Toner Container (Y)
14 Black Toner Container (K)
2
5
6
1 3
7
4
8
9
10
11 12 13 14
