Using the Operation Panel 6-3
Understanding the Operation Panel
The operation panel on the top of the printer has a 2-line by 16-character
liquid crystal display (LCD), eight keys, and three indicators (LED).
Messages that appear on the display and functions of indicators and keys
are explained in this chapter.
Message Display
The message display on the operation panel shows:
• Status information, the ten messages listed below which are displayed
during normal operation.
• Error codes, when the printer requires the operator’s attention; as
explained in the Operation Guide.
