Maintenance 4-9
3 Wipe away the paper dust on the registration roller and the paper
ramp using the cleaning cloth.
4 Push the front cover back in completely.
Paper Ramp
Transfer Belt
(Black)
Cleaning Cloth
Registration
Roller (Metal)
Transfer Roller
(Black)
Duplex Unit
Paper Transfer Unit
Note Be careful not to touch the black transfer roller and
black transfer belt during cleaning as this may adversely
affect print quality.
Note Take care not to get your hands caught in the front
cover when you close it.
To Next Page
