Utax P-4030 MFP

2NM/2NX/2NY/2NZ/2P0/2P6
1-5-57
21. Open the rear cover.
22. Remove the lower interface cover and
the inlet cover.
Figure 1-5-95
23. Remove two screws.
24. Release the hooks by bending both-
side of the right middle cover and then
remove it by pulling and lifting up for-
ward.
Figure 1-5-96
Rear cover
Hook
Inlet cover
Lower
interface cover
Right middle cover
Screw
Hook
Screw
