Utax P-4030 MFP

2NM/2NX/2NY/2NZ/2P0/2P6
1-5-58
25. Pull out the cassette.
26. Remove three screws.
27. Release two hooks by sliding the right
lower cover upward and then remove
the right lower cover.
Figure 1-5-97
28. Release two hooks of the rear left cover
while pulling forward.
29. Remove the rear left cover by rotating.
Figure 1-5-98
Right lower cover
Screw
Screw
Screw
Hooks
Rear left cover
Hooks
