2LV/2L1/2L2/2MS/2MT

1-5-14

6. Pull the connector out.

7. Release the lock lever and then remove

the developer unit upward.

8. Check or replace the developer unit and

refit all the removed parts.

Figure 1-5-22

Developer unit

Connector

Lock lever
