2LV/2L1/2L2/2MS/2MT
1-2-13
1-2-4 Install the memory card (SD card) (option)
Procedure
1. Remove the main PWB assembly from
the machine. (SeePage 1-2-12)
2. SD card is inserted in a SD card slot.
Maximum memory capacity 32 GB.
3. Remove the main PWB assmbly and
the covers.
Figure 1-2-24
SD card
Main PWB assembly
SD card slot
