2LV/2L1/2L2/2MS/2MT

2-4-1

2-4 Appendixes

2-4-1 Appendixes

(1) Maintenance kits

1. 60/50/45 ppm model

2. 40 ppm model

Maintenance part name

Parts No.

Alternative

part No.

Name used in service Name used in parts list

MK-3130/MAINTENANCE KIT

(500,000 images)

MK-3130/MAINTENANCE KIT 1702MT8NL0 072MT8NO

MK-3132/MAINTENANCE KIT

(300,000 sheets)

MK-3132/MAINTENANCE KIT 1702MT8US0 072MT8UO

Transfer roller assembly ROLLER TRANSFER ASSY - -

Drum unit DRUM UNIT - -

Developer unit DLP UNIT - -

Fuser unit FUSER UNIT(KME) - -

Paper feed roller assembly HOLDER FEED ASSY - -

Retard roller assembly RETARD ROLLER ASSY - -

Maintenance part name

Parts No.

Alternative

part No.

Name used in service Name used in parts list

MK-3100/MAINTENANCE KIT

(300,000 sheets)

MK-3100/MAINTENANCE KIT 1702MS8NLP0 072MS8NO

MK-3102/MAINTENANCE KIT

(300,000 images)
