2LV/2L1/2L2/2MS/2MT-5
1-1-2
Resolution
Fine1200, Fast1200(KIR), 600dpi(KIR) , 300dpi
First print time
(A4, feed from cassette)
9.0 s or less
(Excluding time for system stabilization immediately after turning on the main
power.)
Warm-up
time
(22 °C/
71.6 °F,
60% RH)
Power on/
Off mode/
Sleep mode
25 s or less
20 s or less 15 s or less 15 s or less
Low power
mode
-
Paper
capacity
Cassette 500 sheets (80g/m
2
)
MP tray 100 sheets (80 g/m
2
)
Output tray
capacity
Facedown
500 sheets (67g/m
2
)
250 sheets
(67g/m
2
)
Faceup 250 sheets (67g/m
2
)
-
Photoconductor a-Si drum (diameter 30 mm)
Image write system Semiconductor laser
Charging system Contact charger roller method
Developer system
Mono component dry developing method
Toner replenishing: Automatic from the toner container
Transfer system Transfer roller method
Separation system Small diameter separation, dischager needle (DC bias)
Cleaning system Counter blade cleaning + cleaning roller
Charge erasing system Exposure by cleaning lamp (LED)
Fusing system
Heat and pressure fusing with the heat roller and the press roller
Heat source: halogen heater
Abnormally high temperature protection devices: thermostat
CPU PowerPC465, ARM7/ARM9 PowerPC465 *1
Main memory 256 MB / 1280 MB (Standard / Max) *2
Operating system
Windows XP, Windows XP Professional,
Windows Server 2003, Windows Server 2003 x64 Edition,
Windows Vista x86 Edition, Windows Vista x64 Edition,
Windows 7 x86 Edition, Windows 7 x64 Edition,
Windows Server 2008, Windows Server 2008 x64 Edition,
Apple Macintosh OS X
Interface
Standard
USB device interface connector: 1 (USB 2.0)
USB host interface connector: 2 (USB 2.0)
Network interface connector: 1 (10BASE-T/100BASE-TX/1000BASE-T) *3
Option
eKUIO slot: 1
Page description language PRESCRIBE
Emulation PCL6, KPDL3, XPS, Line printer, IBM Proprinter X24E, EPSON LQ-850
Item
Specifications
60 ppm 50 ppm 45 ppm 40 ppm
