Utax P-4030D Service Manual

2LV/2L1/2L2/2MS/2MT
1-4-21
6400 Zero-cross signal error
While fuser heater control is
performed, the zero-cross sig-
nal is not input within 2 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Power source PWB (YC3) and engine PWB
(YC1)
Defective power
source PWB or
engine PWB.
Replace the power source PWB or the
engine PWB and check for correct operation
(see page 1-5-22).
7000 Toner motor error
During driving the toner motor,
an over-current detection sig-
nal is detected at intervals of
10 ms as for 300 accumula-
tion.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Toner motor and drum PWB (YC4)
Drum PWB and relay-L PWB (YC3)
Relay-L PWB and engine PWB (YC2)
Defective toner
motor.
Replace the toner motor.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-22).
7100 Toner sensor error
Sensor output value of 930 or
more continuously for 5 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Toner sensor and drum PWB (YC3)
Drum PWB and relay-L PWB (YC3)
Relay-L PWB and engine PWB (YC2)
Defective toner
sensor.
Replace the developer unit.
(See Page 1-5-13)
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-22).
7400 Developer unit non-install-
ing error
Sensor output value of 31 or
less continuously for 5 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Developer unit and drum PWB (YC3)
Drum PWB and relay-L PWB (YC3)
Relay-L PWB and engine PWB (YC2)
Defective toner
sensor.
Replace the developer unit.
(See Page 1-5-13)
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-22).
Code Contents Causes
Check procedures/
corrective measures

Utax P-4030D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	21 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.5
Total input capacity	500 sheets
Total output capacity	250 sheets
Paper tray media types	Glossy paper, Matte paper, Plain paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	USB 2.0
Optional connectivity	Wireless LAN
Internal memory	128 MB
Compatible memory cards	SD
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	11.5 W
Power consumption (printing)	564 W
Power consumption (PowerSave)	3 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	285 mm
Weight	13500 g
