Operation Panel
4-64
Setup (Wireless network settings)
This selects the settings for Wireless network.
1 In the Wi-Fi Settings menu, press  or  to select Setup.
2 Press [OK]. The Setup menu screen appears.
The options available in the Setup are as follows:
• ConnectionStatus (Wireless network connection status
check)...4-64
• Quick Setup (Quick setup for the wireless network)...4-64
• Custom Setup (Detailed settings for the wireless network)...4-66
ConnectionStatus (Wireless network connection status check)
When the optional Wireless Network Interface Kit (IB-36) is installed, you can check the status of the wireless network.
1 In the Setup menu, press  or  to select ConnectionStatus.
2 Press [OK]. The ConnectionStatus screen appears.
3 Press  or . The NetwkName(SSID) is displayed.
If the entire name shown as the NetwkName(SSID)will not fit on one
line, pressing [Detail] ([Right Select]) changes to a 3-line name
display.
Quick Setup (Quick setup for the wireless network)
When connecting to an access point which supports the automatic wireless network setup, you can select the connection
settings using Quick Setup.
1 In the Setup menu, press  or  to select Quick Setup.
2 Press [OK]. The Quick Setup menu screen appears.
The following operations are possible:
•
AvailableNetwork (Display the access points)...4-65
•
Push Button (Connect using Push Button)...4-65
•
PIN (Device) (Connect using a PIN code (for the Wireless Network
Interface Kit))
...4-66
Note This setting is displayed when the setting for Wi-Fi (Enable/Disable Wi-Fi) on page 4-63 is set to On.
Setup:
ConnectionStatus
Exit
Quick Setup
01
02
Custom Setup
03
ConnectionStatus:
Status
Connected
1/ 2
ConnectionStatus:
Detail
NetwkName(SSID) 2/ 2
ABCDEFGHIJKLMNOPQRST…
Detail:
ABCDEFGHIJKLMNOPQRSTU
VWXYZabcdefghijklmnop
qrstuvwxyz1234567890
Quick Setup:
PIN (Device)
Exit
03
Push Button
02
01
AvailableNetwork
