UTICA BOILERS USC - Thermostat Installation and Lighting; Thermostat Installation Guidelines; Boiler Lighting Procedure

PAGE 10
THERMOSTTHERMOST
THERMOSTTHERMOST
THERMOST
AA
AA
A
T INSTT INST
T INSTT INST
T INST
ALLAALLA
ALLAALLA
ALLA
TIONTION
TIONTION
TION
1. Thermostat should be installed on an inside wall about 4 ft (122 cm) above the floor.
2. NEVER install a thermostat on an outside wall.
3. Do not install a thermostat where it will be affected by:
A. Drafts
B. Hot or cold pipes
C. Sun light
D. Lighting fixtures
E. Television
F. Near a fireplace or chimney
4. Check thermostat operation by raising and lowering thermostat as required to start
and stop the burners.
5. Instructions for the final adjustment of the thermostat are packaged with the thermo-
stat (adjusting heating anticipator, calibration, etc.).
LIGHTING INSTRUCTIONSLIGHTING INSTRUCTIONS
LIGHTING INSTRUCTIONSLIGHTING INSTRUCTIONS
LIGHTING INSTRUCTIONS
WW
WW
W
ARNING:ARNING:
ARNING:ARNING:
ARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS
EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY
DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
CAUTION:CAUTION:
CAUTION:CAUTION:
CAUTION: Before operating, make certain the boiler and system are full of
water to minimum pressure (this is usually 12 lbs. per square inch (82.7 kPa) on most
systems) and system is vented of air. See the operating and lighting instructions.
LIGHTING PROCEDURE FOR BOILER WITHLIGHTING PROCEDURE FOR BOILER WITH
LIGHTING PROCEDURE FOR BOILER WITHLIGHTING PROCEDURE FOR BOILER WITH
LIGHTING PROCEDURE FOR BOILER WITH
A HOA HO
A HOA HO
A HO
T SURFT SURF
T SURFT SURF
T SURF
AA
AA
A
CE PILCE PIL
CE PILCE PIL
CE PIL
OO
OO
O
T SYT SY
T SYT SY
T SY
STEMSTEM
STEMSTEM
STEM
FOR YOUR SAFETY READ BEFORE OPERATINGFOR YOUR SAFETY READ BEFORE OPERATING
FOR YOUR SAFETY READ BEFORE OPERATINGFOR YOUR SAFETY READ BEFORE OPERATING
FOR YOUR SAFETY READ BEFORE OPERATING
1. This appliance is equipped with an ignition device which automatically lights the pilot. Do
not try to light the pilot by hand.
2. Before operating, smell all around the appliance for gas. Be sure to smell next to the
floor because some gas is heavier than air and will settle on the floor.
CAUTION:CAUTION:
CAUTION:CAUTION:
CAUTION:
WHAT TO DO IF YOU SMELL GASWHAT TO DO IF YOU SMELL GAS
WHAT TO DO IF YOU SMELL GASWHAT TO DO IF YOU SMELL GAS
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electric switch.
•
Do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor’s phone.
•
Follow the gas supplier’s instructions.
•
If you cannot reach your gas supplier, call the fire department.
