V-Tec DT601 - Parts and Functions; Terminal Descriptions

-2-
Side View
Mounting box
ID card window
Rainy Cover
DT601/KP/FE
Camera Lens
Speaker
Nameplate
Call Button
Microphone
93 mm
182 mm
Night Light
RF CARD
ID card window
RF CARD
30 mm
DT601F/ID/FE
220 mm
120 mm
RF CARD
Camera Lens
Speaker
Nameplate
Call Button
Microphone
Night Light
Screws for panel
mounting
RF CARD
1.Parts and Functions
2.Terminal Descriptions
1 2 3
Lock Control Jumper
BUS
PL
S+
S-
Main Connect Port
