V-Tec DT601 - DT601 F;ID;FE Mounting; Placing Name Label

-4-
DT601F/ID/FE Mounting
1 2
43
Drill a hole in the wall to match the size of the
mounting box and attach to the wall.
Attach the panel to the mounting box and
use screws supplied to fix the panel
Connect the cable correctly
Placing Name Label
AcDbMLeader (ACDB_MLEADER_CLASS)
AcDbMLeader (ACDB_MLEADER_CLASS)
Use a screwdriver to unscrew the screw, and cock the host , then Placing Name Label.
