V-Tec DT601 - Multi Door Stations Connection; Multi Monitors Connection; Basic IN-OUT Wiring Mode

-7-
Multi Door Stations Connection
100~240VAC
DBC4A1
A B C D
OFF
ON
Impedance
switch
BUS(IM) BUS(DS)
PC6A
AC~
1# Camera2# Camera3# Camera4# Camera
L1 L2 PL S+ S-L1 L2 PL S+ S-
L1 L2 PL S+ S-
L1 L2 PL S+ S-
(Device Address:3) (Device Address:2) (Device Address:1) (Device Address:0)
Basic IN-OUT Wiring Mode
Multi Monitors Connection
RF CARD
Code=14Code=15
(Device Address:0)
BUS(IM) BUS(DS)
PC6A
AC~
100~240VAC
Code=0
NOTE:Here we take DT47MG(the monitor) for example.
