1 - IMPORTANT REMARKS
For any installation problem please contact our Customer Service
at the number +39-0172.812411 operating Monday to Friday
from 8:30 to 12:30 and from 14:00 to 18:00.
V2 has the right to modify the product without previous
notice; it also declines any responsibility to damage or
injury to people or things caused by improper use or wrong
installation.
m Please read this instruction manual very carefully
before installing and programming your control unit.
• This instruction manual is only for qualified technicians, who
specialize in installations and automations.
• The contents of this instruction manual do not concern the end
user.
• Every programming and/or every maintenance service should
be done only by qualified technicians.
AUTOMATION MUST BE IMPLEMENTED IN COMPLIANCE
WITH THE EUROPEAN REGULATIONS IN FORCE:
EN 60204-1 (Machinery safety. electrical equipment of
machines, part 1: general rules)
EN 12445 (Safe use of automated locking devices,
test methods)
EN 12453 (Safe use of automated locking devices,
requirements)
• The installer must provide for a device (es. magnetotermical
switch) ensuring the omnipolar sectioning of the equipment
from the power supply. The standards require a separation of
the contacts of at least 3 mm in each pole (EN 60335-1).
• After making connections on the terminal board, use one
hose clamp to fix dangerous voltage wires near the terminal
board and another hose clamp to fix safety low voltage wires
used for accessories connection; this way, in case of accidental
detachment of a conducting wire, dangerous voltage parts will
not come into contact with safety low voltage ones.
• The plastic case has an IP55 insulation; to connect flexible or
rigid pipes, use pipefittings having the same insulation level.
• Installation requires mechanical and electrical skills, therefore it
shall be carried out by qualified personnel only, who can issue
the Compliance Certificate concerning the whole installation
(EEC Machine Directive 89/392, Annex IIA).
• The automated vehicular gates shall comply with the following
rules: EN 12453, EN 12445, EN 12978 as well as any local rule
in force.
• Also the automation upstream electric system shall comply with
the laws and rules in force and be carried out workmanlike.
• The door thrust force adjustment shall be measured by means
of a proper tool and adjusted according to the max. limits,
which EN 12453 allows.
• We recommend to make use of an emergency button, to be
installed by the automation (connected to the control unit
STOP input) so that the gate may be immediately stopped in
case of danger.
• Always remember to connect the earth according to current
standards (EN 60335-1, EN 60204-1).
2 - DECLARATION OF CONFORMITY
V2 S.p.A. hereby declare that CITY2+ products conform to the
essential requirements established in the following directives:
• 2014/30/UE (EMC Directive)
• 2014/35/UE (Low Voltage Directive)
• ROHS2 2011/65/CE
Racconigi, 01/06/2015
V2 S.p.A. legal representative.
Antonio Livio Costamagna
3 - TECHNICAL SPECIFICATIONS
CITY2+ CITY2+L CITY2+BC
Power supply 230V / 50Hz 230V / 50Hz ECO-LOGIC
Maximum load
consumed from
the mains with
two motors +
accessories
250W 150W 250W
Nominal load for
each motor output
80W 60W 80W
Max accessories
load 24Vdc
7W 7W 7W
Work cycle (*) 80% 60% 80%
Protection fuse 2,5A 2,5A -
Weight 3000 g 1000 g 1000 g
Dimensions 295 x 230 x 100 mm
Working
temperature
-20 ÷ +60°C
Protection IP55
(*) the work cycle is related to the following conditions:
2 motors @ nominal load
Room temperature = 25°C
