ENGLISH
13
TECHNICAL SPECIFICATIONSEC DECLARATION OF INCORPORATION FOR
P
ARTLY COMPLETED MACHINERY
(Directive 2006/42/EC, Annex II-B)
The manufacturer (*) V2 S.p.A., headquarters in
Corso Principi di Piemonte 65, 12035, Racconigi (CN), Italy
Under its sole responsibility hereby declares that:
the partly completed machinery model(s):
JEDI-700 (*), JEDI-700-120V
JEDI-1000 (*), JEDI-1000-120V
Identification number and year of manufacturing: typed on
nameplate
Description: electromechanical actuator for garage doors
- is intended to be installed on garage doors to create a machine
according to the provisions of the Directive 2006/42/EC.
The machinery must not be put into service until the final
machinery into which it has to be incorporated has been declared
in conformity with the provisions of the Directive 2006/42/EC
(annex II-A).
- is compliant with the applicable essential safety requirements
of the following Directives:
Machinery Directive 2006/42/EC (annex I, chapter 1)
Low Voltage Directive 2006/95/EC
Electromagnetic Compatibility Directive 2004/108/EC
Radio Directive 99/05/EC
Directive ROHS2 2011/65/EC
The relevant technical documentation is available at the national
authorities’ request after justifiable request to:
V2 S.p.A., Corso Principi di Piemonte 65,
12035, Racconigi (CN), Italy
The person empowered to draw up the declaration and to provide
the technical documentation:
Cosimo De Falco
Legal representative of V2 S.p.A.
Racconigi, 11th January 2010
(*) made in extra EU Countries on behalf of V2 S.p.A.
JEDI-700 JEDI-1000
Power supply 230Vac - 50Hz 230Vac - 50Hz
Absorbed power 100W 160W
Max accessories load 24V 12W 12W
Protection fuses SOURCE = 2,5A SOURCE = 2,5A
D
oor area
< 1
0m
2
< 1
5m
2
Average speed 110mm/s 110mm/s
Peak force 700N 1000N
Nominal force 550N 850N
Working temperature -20 ÷ +40 °C -20 ÷ +40 °C
Rated Operating Time > 4 min. > 4 min.
Protection degree IP20 IP20
Weight 12Kg 12Kg
JEDI-700-120V JEDI-1000-120V
Power supply 120Vac - 60Hz 120Vac - 60Hz
Absorbed power 100W 160W
Max accessories load 24V 12W 12W
Protection fuses SOURCE = 3,5A SOURCE = 3,5A
Door area < 10m
2
< 15m
2
Average speed 110mm/s 110mm/s
Peak force 700N 1000N
Nominal force 550N 850N
Working temperature -20 ÷ +40 °C -20 ÷ +40 °C
Rated Operating Time > 4 min. > 4 min.
Protection degree IP20 IP20
Weight 12Kg 12Kg
