3 RECEIVING THE DELIVERY
3.1 CONTENTS OF THE DELIVERY
The contents of the delivery
•
The AC drive and the options that you ordered
•
An accessories bag
•
The parts for the marine option
•
Safety Instructions, and the manuals for the options that you ordered
•
Installation Manual and Application Manual if you ordered them, or Quick Guide
•
The Marine Installation Guide
3.2 REMOVING THE PACKAGING AND LIFTING THE AC DRIVE
3.2.1 WEIGHT OF THE AC DRIVE
Table 2: The weights of the wall-mounted drives with the marine option
Enclosure size Weight [kg] Weight [lb.]
Wall-mounted drive, MR4 6.1 13.4
Wall-mounted drive, MR5 10.1 22.3
Wall-mounted drive, MR6 20.1 44.3
Wall-mounted drive, MR7 37.6 82.9
Wall-mounted drive, MR8 76.2 168.0
Wall-mounted drive, MR9 134.6 296.7
Table 3: The weights of the enclosed drives with the marine option
Enclosure size Weight [kg] Weight [lb.] Weight with the
common mode
and du/dt filters
[kg]
Weight with the
common mode
and du/dt filters
[lb.]
Enclosed drive, MR8 224 494 254 560
Enclosed drive, MR9 296 653 336 741
Enclosed drive, MR10 446 983 486 1071
Enclosed drive, MR12 2 x 446 2 x 983 2 x 486 2 x 1071
