3.2.2 LIFTING THE AC DRIVE
LIFTING THE ENCLOSED DRIVE
1 When you lift the enclosed drive to an upright
position, be careful not to damage the springs at
the bottom of the drive.
•
When the drive tilts, the springs are squeezed.
To prevent damage to the springs, do not keep
the drive tilted for an unnecessary long time.
•
When the springs are squeezed, they can
bounce suddenly and cause damage to the
equipment.
A
B
A. The lifting hole
B. The springs at the bottom
WARNING!
Be careful when you lift the enclosed drive to an upright position. If the springs are
squeezed for too long, they can become damaged. Also, the springs can bounce
suddenly and cause injury to the personnel and/or damage to the equipment.
