installation vacon • 7
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
2
.
Figure 8: Attaching the PE-plate and API cable support, MI1 - MI3
Figure 9: Attaching the PE-plate and API cable support, MI4 - MI5
Attach this plate
BEFORE i nstalling
the power ca bl es
Attach the support
AF TER i nstal lin g
the power cables
Attach the support
AF TER i nstal lin g
Attach this plate
BEFORE installing
the pow er cabl es
