28 • vacon modbus
Tel.+358 (0)201 2121 • Fax +358 (0)201 212 205
6
6.2.4.1
Status word
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
- - - - - UVFS
DDI
R
TCSPDL FR Z
ARE
F
W FLT DIR RUN RDY
Information about the status of the device and messages is indicated in the
Status word
. The
Status
word
is composed of 16 bits that have the following meanings:
Value = 0 Value = 1
0 Not Ready Ready
1 STOP RUN
2 Clockwise Counterclockwise
3 - Faulted
4 - Warning
5 Ref. frequency not reached Ref. Frequency reached
6 - Motor is running at zero speed
7 Flux Not Ready Flux Ready
8 TC Speed Limit Active TC Speed Limit Not Active
9 Detected Encoder Direction Clockwise Encoder Direction Counterclockwise
10 UV Fast Stop Active UV Fast Stop Not Active
11...15 Not In use Not In use
Table 15. Status word bit descriptions
6.2.4.2
General status word
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
I/O PANEL FB - - - - - - - - - - - -
0...12 Not in use
13 Fieldbus control, (
= FB control active)
14 Panel control, (
= Panel control active)
15 I/O Control, (
= I/O control active)
Table 16. General status word bit descriptions
