7.3 N2 POINT MAP
7.3.1 Analogue Inputs (AI)
NPT
NPA
Description
Units
Note
AI 1 Speed Setpoint Hz 2 decimals
AI
2
Output Speed
Hz
2 decimals
AI 3 Motor Speed Rpm 0 decimal
AI 4 Load (power) % 1 decimal
AI 5 Megawatt Hours MWh Total Counter
AI 6 Motor Current A 2 decimal
AI 7 Bus Voltage V 0 decimal
AI 8 Motor Volts V 1 decimal
AI 9 Heatsink Temperature
°
C
0 decimal
AI 10 Motor Torque % 1 decimal
AI 11 Operating Days (trip) Day 0 decimal
AI 12 Operating Hours (trip) Hour 0 decimal
AI 13 Kilowatt Hours (trip) kWh Trip Counter
AI 14 Torque Reference
1)
% 1 decimal
AI 15
Motor Temperature
Rise
1)
% 1 decimal
AI 16 FBProcessDataOut1
2)
-32768 to
+32767
0 decimal
AI 17 FBProcessDataOut2
2)
-32768 to
+32767
0 decimal
AI 18 FBProcessDataOut3
2)
-32768 to
+32767
0 decimal
AI 19 FBProcessDataOut4
2)
-32768 to
+32767
0 decimal
AI 20 FBProcessDataOut5
2)
-32768 to
+32767
0 decimal
AI 21 FBProcessDataOut6
2)
-32768 to
+32767
0 decimal
AI 22 FBProcessDataOut7
2)
-32768 to
+32767
0 decimal
AI 23 FBProcessDataOut8
2)
-32768 to
+32767
0 decimal
Table 19.
1)
Torque Reference (AI-14) and Motor Temperature Rise (AI-15) NOT supported in NXL
2)
These analogue inputs are application specific.
