Vacon NX OPTC2 User Manual

metasys n2 vacon • 37
24-hour support +358 (0)40 8371 150 • Email: vacon@vacon.com
7
7.3.2 Binary Inputs (BI)
NPT
NPA
Description
0 =
1 =
BI 1 Ready Not Ready Ready
BI 2 Run Stop Run
BI 3 Direction Clockwise Counterclockwise
BI 4 Faulted Not Faulted Faulted
BI 5 Warning Not Warning Warning
BI 6 Ref. Frequency reached False True
BI 7 Motor running zero speed False True
BI 8 General 0
3)
0 1
BI 9 General 1
3)
0 1
BI 10 General 2
3)
0 1
BI 11 General 3
3)
0 1
BI 12 General 4
3)
0 1
BI 13 General 5
3)
0 1
BI 14 General 6
3)
0 1
BI 15 General 7
3)
0 1
Table 20.
3)
These binary inputs are application specific. They are read from the drives General Status
Word.
7.3.3
Analogue Outputs (AO)
NPT
NPA
Description
Units
Note
AO 1 Comms Speed % 2 decimals
AO 2
Current Limit
A 2 decimals
AO
3
Minimum Speed
Hz
2 decimals
AO 4 Maximum Speed Hz 2 decimals
AO 5 Accel Time s 1 decimal
AO 6 Decel Time s 1 decimal
AO 7 FBProcessDataIN 1
4)
-32768 to +32767 2 decimals
AO 8 FBProcessDataIN 2
4)
-32768 to +32767 2 decimals
AO 9 FBProcessDataIN 3
4)
-32768 to +32767 2 decimals
AO 10 FBProcessDataIN 4
4)
-32768 to +32767 2 decimals
Table 21.
4)
These Analogue Outputs are application specific.
