38 • vacon metasys n2
Tel.+358 (0)201 2121 • Fax +358 (0)201 212 205
7
7.3.4
Binary Outputs (BO)
BO 1 Comms Start/Stop Stop Start
BO 2 Comms Forward/Reverse Forward Reverse
BO 3 Reset Fault N/A Reset
BO 4 FBFixedControlWord Bit_3
5)
- -
BO 5 FBFixedControlWord Bit_4
5)
- -
BO 6 FBFixedControlWord Bit_5
5)
- -
BO 7 FBFixedControlWord Bit_6
5)
- -
BO 8 FBFixedControlWord Bit_7
5)
- -
BO 9 FBFixedControlWord Bit_8
5)
- -
BO 10 FBFixedControlWord Bit_9
5)
- -
BO 11 FBFixedControlWord Bit_10
5)
- -
BO 12 FBFixedControlWord Bit_11
5)
- -
BO 13 FBFixedControlWord Bit_12
5)
- -
BO 14 FBFixedControlWord Bit_13
5)
- -
BO 15 FBFixedControlWord Bit_14
5)
- -
BO 16 FBFixedControlWord Bit_15
5)
- -
Table 22.
5)
These Binary Outputs are application specific.
7.3.5
Internal Integers (ADI)
ADI 1 Active Fault Code -
Table 23.
