➨ Unscrewhosenozzle,orhosenozzlewithcoupling,using
an open-ended wrench.
➨ Unscrew elbow tting with silencer at the outlet of the
pump.
➨ DependingonBVCversion,removeconnectiontubingat
thehosenozzleordetachquickcoupling.
➨ Remove bottle from support.
➨ Unscrewcover,payingattentiontowashers.
➨ Fixcoverplateatthepumphousingusingadhesivetape.
Disassembling
