AV Bridge MATRIX PRO
AV Bridge Matrix Pro Manual - Document Number 342-0915 Rev C Page 57 of 68
Camera ccu set
Set CCU values for the specified camera. At the risk of stating the obvious, all options require option parameters.
Synopsis
camera [1-3] ccu set {auto_white_balance {on | off} I red_gain [0-255] | blue_gain [0-255]
|backlight_compensation | auto_iris | iris | gain | detail | chroma}
Required
[1 – 3]
Specify which camera’s values to set.
Options
auto_white_balance [on
| off]
Set auto white balance mode on or off.
red_gain [0 – 255]
Set the red gain value to an integer between 0 and 255.
blue_gain [0 – 255]
Set the blue gain value to an integer between 0 and 255.
backlight_compensation
[on | off]
Use backlight compensation or turn it off.
auto_iris [on | off]
Set auto-iris mode on or off. If auto-iris is on, it overrides any
manual iris setting. The manual iris value will persist and be
recalled when setting is changed back to manual.
iris [0 – 13]
Set the iris value to an integer between 0 and 13. This will
over-ride any auto-iris setting
gain [0 – 13]
Set gain to an integer between 0 and 13.
detail [0 – 15]
Set detail value to an integer between 0 and 15.
chroma [0 – 14]
Set chroma value to an integer between 0 and 14.
Examples
camera 1 ccu set auto_iris off
Sets the camera 1 auto_iris off
camera 2 ccu set red_gain 10
Sets the camera 2 red gain to be 10
Camera ccu get
Retrieve current CCU values for the specified camera.
Synopsis
camera [1-3] ccu get {auto_white_balance I red_gain | blue_gain |
backlight_compensation | auto_iris | iris | gain | detail | chroma}
Required
[1 – 3]
Specify which camera’s values to get
Options
auto_white_balance
Gets auto white balance mode
red_gain
Gets red gain value
blue_gain
Gets blue gain value
backlight_compensation
Gets backlight compensation mode
auto_iris
Gets auto-iris mode
iris
Gets iris value
gain
Gets gain value
detail
Gets detail value
chroma
Gets chroma value
Examples
camera 3 ccu get iris
Gets the iris value for camera input 3
camera 1 ccu get red_gain
Gets the red_gain value for camera 1
