5Installation Manual auroMATIC 560
5.1 Wiring according to hydraulic plan
To simplify installation, three hydraulic plans are stored
in the controller. The relevant plan must be selected
according to the system configuration used.
Each of the hydraulic plans show a possible system config-
uration in which some system components are optional.
Caution!
These hydraulic plans are only schematic repre-
sentations and cannot be used for the prepara-
tion of the hydraulic piping.
Hydraulic plan Bivalent cylinder
Number of
collectors
Circulation pump
connected
Solid-fuel boiler
connected
2nd Cylinder or
swimming pool
connected
1X1yesnoyes
2 X 2 no no yes
3X1noyesyes
Table 5.1 System configuration
Electrical installation 5
