04 Burner
ecoTEC plus 824 VUW 246/3-5 + R1
ecoTEC plus 831 VUW 316/3-5 + R1
ecoTEC plus 837 VUW 376/3-5 R1
Pos. Art.-No Part Type, note
02-04-038
00 0020010641 conversion set H -> P (not shown)
00 0020010642 conversion set P -> H (not shown)
01 049324 burner VUW 246/3-5, with parts 02, 03
01 049324 burner VUW 246/3-5 R1, with parts 02, 03
01 049345 burner VUW 316/3-5, with parts 02, 03
01 049345 burner VUW 316/3-5 R1, with parts 02, 03
01 050430 burner VUW 376/3-5 R1, with parts 02, 03
02 981103 sealing ring, cpl.
03 105900 screw, cpl. (set of 10)
04 114828 flanged nut
05 161245 inspection glass
06 090709 ignition/monitoring electrode
07 980961 gasket electrode
08 118883 screw
09 193590 ignition cable
10 193593 fan with parts 11, 12
11 981104 packing ring cpl.
12 193594 packingring cpl.
13 053470 gas valve VUW 246/3-5, with parts 11, 14, 21
13 053470 gas valve VUW 246/3-5 R1, with parts 11, 14, 21
13 053471 gas valve VUW 316/3-5, with parts 11, 14, 21
13 053471 gas valve VUW 316/3-5 R1, with parts 11, 14, 21
13 053500 gas valve VUW 376/3-5 R1, with parts 11, 14, 21
14 981142 packingring (set of 10)
16 193586 harness VUW 246/3-5
16 193586 harness VUW 246/3-5 R1
16 193586 harness VUW 316/3-5
16 193586 harness VUW 316/3-5 R1
16 0020025036 harness VUW 376/3-5 R1
17 193595 insulation with parts 02, 03
18 - - not available as spare part, see pos. 30
19 981107 packing ring cpl.
20 193597 screw, cpl. (set of 10)
21 0020025929 sealing gasket
22 193599 air inlet duct, cpl. VUW 246/3-5, with part 23
22 193599 air inlet duct, cpl. VUW 246/3-5 R1, with part 23
22 103404 air inlet duct, cpl. VUW 316/3-5, with part 23
22 103404 air inlet duct, cpl. VUW 316/3-5 R1, with part 23
22 0020025039 air inlet duct, cpl. VUW 376/3-5 R1, with part 23
23 981111 packingring cpl.
24 103405 support, cpl.
25 235756 screw
26 - - not available as spare part, see pos. 30
27 180945 gas pipe with part 28
28 0020010868 adaptor piece (gas valve)
29 982319 O-ring seal
30 0020010867 flange (set) with parts 02, 03, 04, 05, 07, 08, 12, 14, 17, 19, 20, 21
Subject to alteration !
Attention: Please take the gross price from the valid price list !
5

Vaillant ecoTEC plus 624 Specifications

General

Model	ecoTEC plus 624
Category	Boiler
Output	24 kW
Dimensions (H x W x D)	720 x 440 x 338 mm
Mounting	Wall-mounted
Fuel	Natural Gas
Warranty	5 years
Type	Combination
Central Heating Flow Temperature Range	30°C to 80°C
