26 Installation and maintenance instructions atmoMAG 0020189893_03
MAG 14-0/1 GX MAG 14-0/1 XI
Boiler dimension, height
680 mm 680 mm
Boiler dimension, width
350 mm 350 mm
Boiler dimension, depth (incl.
rotary switch)
270 mm 270 mm
Flue pipe connection diameter
130 mm 130 mm
Gas connection diameter
1/2″ conical 1/2″ conical
Weight, approx.
11.5 kg 11.5 kg
Test symbol/registration no.
1008CP2793 1008CP2793
Technical data – Power/load
Applicability: Germany, Austria, Switzerland
MAG AT 11-0/1 GX
H
MAG AT 14-0/1 GX
H
MAG 11-0/1 GX MAG 11-0/1 XI
Hot water volume at the "hot"
temperature selection setting
2.8 … 5.5 l/min 3.7 … 7.0 l/min 2.8 … 5.5 l/min 2.6 … 5.5 l/min
Hot water volume at the "warm"
temperature selection setting
5.7 … 11.0 l/min 7.5 … 14.0 l/min 5.7 … 11.0 l/min 5.5 … 11.0 l/min
Max. water outlet temperature at
an inlet temperature of 10 °C
65 ℃ 65 ℃ 65 ℃ 65 ℃
Max. heat in-
put (in relation
to the heating
value H
i
)
Germany
— — 21.7 kW 21.7 kW
Switzerland
— — 21.7 kW 21.7 kW
Austria
21.0 kW 26.1 kW — —
Min. heat input (Q
min.
)
9.8 kW 12.2 kW 9.8 kW 9.8 kW
Max. heat out-
put (P
max.
)
Germany
— — 19.2 kW 19.2 kW
Switzerland
— — 19.2 kW 19.2 kW
Austria
18.2 kW 22.7 kW — —
Min. heat output (P
min.
)
8.4 kW 10.4 kW 8.4 kW 8.4 kW
Control range Germany
— — 8.4 … 19.2 kW 8.4 … 19.2 kW
Switzerland
— — 8.4 … 19.2 kW 8.4 … 19.2 kW
Austria
8.4 … 18.2 kW 10.4 … 22.7 kW — —
Max. permissible water pressure
P
w max.
1.3 MPa
(13.0 bar)
1.3 MPa
(13.0 bar)
1.3 MPa
(13.0 bar)
1.3 MPa
(13.0 bar)
Min. permissible water pressure
P
w min.
40 kPa
(400 mbar)
45 kPa
(450 mbar)
40 kPa
(400 mbar)
15 kPa
(150 mbar)
Flue gas temperature at max. heat
output
160 ℃ 165 ℃ 160 ℃ 160 ℃
Flue gas temperature at min. heat
output
110 ℃ 110 ℃ 110 ℃ 110 ℃
Max. flue gas
mass rate
Germany
— — 13.7 g/s 13.7 g/s
Switzerland
— — 13.7 g/s 13.7 g/s
Austria
13.2 g/s 17.5 g/s — —
Min. flue gas mass rate
13.3 g/s 17.1 g/s 13.3 g/s 13.3 g/s
Min. chimney draught
1.5 Pa 1.5 Pa 1.5 Pa 1.5 Pa
Min. chimney draught when using
a thermal flue non-return flap
10.0 Pa 10.0 Pa 10.0 Pa 10.0 Pa
MAG 14-0/1 GX MAG 14-0/1 XI
Hot water volume at the "hot"
temperature selection setting
3.7 … 7.0 l/min 3.7 … 7.0 l/min
Hot water volume at the "warm"
temperature selection setting
7.5 … 14.0 l/min 7.0 … 14.0 l/min
Max. water outlet temperature at
an inlet temperature of 10 °C
65 ℃ 65 ℃
