Appendix
0020189893_03 atmoMAG Installation and maintenance instructions 27
MAG 14-0/1 GX MAG 14-0/1 XI
Max. heat in-
put (in relation
to the heating
value H
i
)
Germany
27.7 kW 27.7 kW
Switzerland
27.7 kW 27.7 kW
Austria
— —
Min. heat input (Q
min.
)
12.2 kW 12.2 kW
Max. heat out-
put (P
max.
)
Germany
24.4 kW 24.4 kW
Switzerland
24.4 kW 24.4 kW
Austria
— —
Min. heat output (P
min.
)
10.4 kW 10.4 kW
Control range Germany
10.4 … 24.4 kW 10.4 … 24.4 kW
Switzerland
10.4 … 24.4 kW 10.4 … 24.4 kW
Austria
— —
Max. permissible water pressure
P
w max.
1.3 MPa
(13.0 bar)
1.3 MPa
(13.0 bar)
Min. permissible water pressure
P
w min.
45 kPa
(450 mbar)
22 kPa
(220 mbar)
Flue gas temperature at max. heat
output
165 ℃ 165 ℃
Flue gas temperature at min. heat
output
110 ℃ 110 ℃
Max. flue gas
mass rate
Germany
18.6 g/s 18.6 g/s
Switzerland
18.6 g/s 18.6 g/s
Austria
— —
Min. flue gas mass rate
17.1 g/s 17.1 g/s
Min. chimney draught
1.5 Pa 1.5 Pa
Min. chimney draught when using
a thermal flue non-return flap
10.0 Pa 10.0 Pa
Technical data – Natural gas G20
Applicability: Germany, Switzerland, Austria
MAG AT 11-0/1 GX
H
MAG AT 14-0/1 GX
H
MAG 11-0/1 GX MAG 11-0/1 XI
Gas connection value at max. heat
output (DE)
— — 2.3 m³/h 2.3 m³/h
Gas connection value at max. heat
output (CH)
— — 2.3 m³/h 2.3 m³/h
Gas connection value at max. heat
output (AT)
2.2 m³/h 2.76 m³/h — —
Gas connection pressure
1.7 … 2.5 kPa
(17.0 … 25.0 mbar)
1.7 … 2.5 kPa
(17.0 … 25.0 mbar)
1.7 … 2.5 kPa
(17.0 … 25.0 mbar)
1.7 … 2.5 kPa
(17.0 … 25.0 mbar)
Burner jet
1.18 mm 1.3 mm 1.18 mm 1.18 mm
Burner jet (AT)
1.10 mm 1.3 mm — —
Min. air requirement for combus-
tion
23.3 m³/h 29.6 m³/h 23.3 m³/h 23.3 m³/h
Min. air requirement for combus-
tion (AT)
22.3 m³/h 27.9 m³/h 22.3 m³/h 22.3 m³/h
MAG 14-0/1 GX MAG 14-0/1 XI
Gas connection value at max. heat
output (DE)
2.93 m³/h 2.93 m³/h
Gas connection value at max. heat
output (CH)
2.95 m³/h 2.95 m³/h
Gas connection value at max. heat
output (AT)
— —
Gas connection pressure
1.7 … 2.5 kPa
(17.0 … 25.0 mbar)
1.7 … 2.5 kPa
(17.0 … 25.0 mbar)
