28 Installation and maintenance instructions atmoMAG 0020189893_03
MAG 14-0/1 GX MAG 14-0/1 XI
Burner jet
1.5 mm 1.3 mm
Burner jet (AT)
— —
Min. air requirement for combus-
tion
29.6 m³/h 29.6 m³/h
Min. air requirement for combus-
tion (AT)
27.9 m³/h 27.9 m³/h
Technical data – Natural gas G25
Applicability: Germany
MAG 11-0/1 GX MAG 11-0/1 XI MAG 14-0/1 GX MAG 14-0/1 XI
Gas connection value at max. heat
output
2.7 m³/h 2.7 m³/h 3.5 m³/h 3.5 m³/h
Gas connection pressure
1.7 … 2.5 kPa
(17.0 … 25.0 mbar)
1.7 … 2.5 kPa
(17.0 … 25.0 mbar)
1.7 … 2.5 kPa
(17.0 … 25.0 mbar)
1.7 … 2.5 kPa
(17.0 … 25.0 mbar)
Burner jet
1.35 mm 1.35 mm 1.5 mm 1.5 mm
Min. air requirement for combus-
tion
23.2 m³/h 23.2 m³/h 30.0 m³/h 30.0 m³/h
Technical data – Liquid gas G31
Applicability: Germany, Austria, Switzerland
MAG AT 11-0/1 GX
H
MAG 11-0/1 GX MAG 11-0/1 XI MAG 14-0/1 GX
Gas connection value at max. heat
output
— 1.7 kg/h 1.7 kg/h 2.18 kg/h
Gas connection value at max. heat
output (AT)
1.65 kg/h — — —
Gas connection pressure
4.25 … 5.75 kPa
(42.50
… 57.50 mbar)
4.25 … 5.75 kPa
(42.50
… 57.50 mbar)
4.25 … 5.75 kPa
(42.50
… 57.50 mbar)
4.25 … 5.75 kPa
(42.50
… 57.50 mbar)
Burner jet
0.72 mm 0.72 mm 0.72 mm 0.76 mm
Min. air requirement for combus-
tion
— 20.6 m³/h 20.6 m³/h 26.5 m³/h
Min. air requirement for combus-
tion (AT)
20.0 m³/h — — —
MAG 14-0/1 XI
Gas connection value at max. heat
output
2.18 kg/h
Gas connection value at max. heat
output (AT)
—
Gas connection pressure
4.25 … 5.75 kPa
(42.50
… 57.50 mbar)
Burner jet
0.76 mm
Min. air requirement for combus-
tion
26.5 m³/h
Min. air requirement for combus-
tion (AT)
—
