0020291525_04 Installation and maintenance instructions 69
VIH QW 190/6 E GB
Heat-up time in accordance with
DIN EN 16147 to target cylinder
temperature, A7 with an outdoor
unit up to 7 kW
125 min
Power consumption during
standby in accordance with DIN
EN 16147, A7 – with an outdoor
unit up to 7 kW
45 W
Coefficient of performance
(COPdhw) in accordance with EN
16147, A7, XL profile – with an
outdoor unit up to 7 kW
2.55
Reference domestic hot water
temperature in accordance with
DIN EN 16147, A7 – with an out-
door unit up to 7 kW
51.6 ℃
Mixed water volume V40 in ac-
cordance with DIN EN 16147, A7
– with an outdoor unit up to 7 kW
246 l
Heat-up time in accordance with
DIN EN 16147 to target cylinder
temperature, A7 with an outdoor
unit up to 12 kW
80 min
Power consumption during
standby in accordance with DIN
EN 16147, A7 – with an outdoor
unit up to 12 kW
39 W
Coefficient of performance
(COPdhw) in accordance with EN
16147, A7, XL profile – with an
outdoor unit up to 12 kW
2.61
Reference domestic hot water
temperature in accordance with
DIN EN 16147, A7 – with an out-
door unit up to 12 kW
52.1 ℃
Mixed water volume V40 in ac-
cordance with DIN EN 16147, A7
– with an outdoor unit up to 12 kW
258 l
Technical data – Electrics
VIH QW 190/6 E GB
Rated voltage
230 V (+10%/-15%),
50 Hz, 1~/N/PE
Rated voltage
400 V (+10%/-15%),
50 Hz, 3~/N/PE
Rated power, maximum
5.4 kW
Rated current, maximum, 230 V
23.5 A
Rated current, maximum, 400 V
13.6 A
Overvoltage category
II
Fuse type, characteristic C,
slow-blow, three-pole switching
(disconnection of the three mains
connection lines in one switching
operation)
Design in accordance
with the selected
connection diagrams
Results regarding BS 7206
VIH QW 190/6 E GB
Reheat test time
70% of the storage ca-
pacity back to 65 °C:
27:30 minutes
Supply temperature test time
16 °C to 65 °C: 35
minutes
