QUICK GUIDE ____________________________________________________________________
16 __________________________________________________________________ M211247EN-C
Inputs and Outputs
Property Description / Value
Two-wire output signal 4 ... 20 mA (loop powered)
External loop voltage 10 ... 30 VDC (R
L
= 0 ohms)
20 ... 30 VDC (R
L
< 500 ohms)
Max. additional error caused by the
analog outputs after calibration at
+20 °C ambient temperature
±0.1% of full scale output current
Temperature dependence of the
analog outputs
±0.005 %/°C full scale output current
Mechanics Specifications
Property Description / Value
Material
Transmitter housing PBT plastic
Display window PC plastic
Probe body Stainless steel (AISI 316)
Probe grid filter Chrome coated ABS plastic
Housing classification IP65 (NEMA 4)
Connections
Current loop outputs Screw terminals 0.5 ... 1.5 mm²
Probe interface 4-pin M8 female panel connector
Probe cable lengths 3 m, 5 m, 10 m, cables can be
cascaded up to 50 m
Display (optional) LCD display without backlight
Weight (Wall model, including probe)
Weight (10m cable model)
270 g
540 g
