MI70 status icons
Table 1. MI70 status iconsIcons that inform you about the status of MI70 (for example, battery status and alarm
notification) are shown on the upper left corner of the display. Multiple icons can be shown simultaneously.
Icon Description
Battery status icon. The icon can show the following info:
0 … 8 bars, no animation:
batteries are in use, a charger is not connected
if a charger is connected: non-rechargeable batteries installed
if a charger is connected: waiting for the battery temperature to settle between
0 … +40 °C (+32 … +104 °F)
if a charger is connected and the icon remains at 8/8 bars: the battery is full
Animated battery status icon: battery is charging (or recovering after emptying out
completely). The charging animation is shown also when the indicator is powered off.
Battery icon not present: batteries are not installed
The battery can no longer be charged and must be replaced. If the indicator is powered on, a
notification about not being able to charge the battery is shown on the MI70 screen.
You can order replacement batteries from Vaisala (item code 26755).
Recording icon. Shows that the measurements are being recorded. The bar shows for how
long the recording will continue (a set time limit or until the memory runs out). The recording
icon and bar are shown also when the indicator is powered off.
Calibration reminder icon. Appears when a calibration reminder has been set to inform that a
user-defined interval has passed and calibration is due.
Analog output icon. Shown when the analog output mode is in use.
PC connection icon. Shown when the indicator is connected to a PC with a cable.
Alarm icon. Shown when the measurement has reached a user-defined alarm limit.
Related reference
MI70 battery status information
Setting calibration reminder
Setting an alarm
Selecting and scaling analog output
Recording data
Transferring recorded data to PC with MI70 Link
