Valeo REVO-E - 4.2 Lifting Frame

Installation instructions REVO-E Installation of the air-conditioning unit
29
4.2. Lifting frame
Figure 11:
4x safety hooks - 90° rotatable
4x suction cups for covers
DETAIL A
safety hook
fixed washer
spring
portable washer
Hook version adjustable for
different center of gravity
depending on equipment
